2.3L Ecoboost VCT Camshafts
- Brand: Esslinger Engineering
- Product Code: 2.3L Ecoboost VCT Camshafts
- Availability: In Stock
(Update) Esslinger Ecoboost cams were used by Bill Putnam/ Team UPR in their 2015 Mustang to set the World Record 1/4mi. elapsed time for ALL Ecoboost..
Available Options
(Update) Esslinger Ecoboost cams were used by Bill Putnam/ Team UPR in their 2015 Mustang to set the World Record 1/4mi. elapsed time for ALL Ecoboost vehicles with a 9.467 @ 144.6mph!
We sell two different styles of cam for use in engines that maintain the use of your variable cam timing (VCT). The Stage 3 & 4 cams require an upgraded valvespring kit to control the extra lift, and the Stage 2 cams are designed to work with the OEM Ford valve springs*.
Specifications:
Esslinger Stage 2 Ecoboost Cams
Intake: .346", 216dur @ .050"
Exhaust: .345", 209dur @ .050"
Esslinger Stage 3 Ecoboost Cams
Intake: .438" lift, 226dur @ .050"
Exhaust: .405" lift, 218dur @ .050"
Esslinger Stage 4 Ecoboost Cams
Intake: .439" lift, 239dur @ .050"
Exhaust: .438" lift, 226dur @ .050"
Stock 2.3L Mustang & Focus RS Ecoboost Cam Specs:
Intake: .327" lift, 197 duration @ .050"
Exhaust:.293" lift, 187 duration @ 050"
Ford Racing 2.3L Ecoboost Cams:
Intake: .354" lift, 206 duration @ 050"
Exhaust: .306" lift, 203 duration @ .050"
Both our Stage 2, 3, & 4 Ecoboost exhaust cams come with a 4-lobe High Pressure Fuel Pump drive, not the 3-lobe set-up that a 2.0L Ecoboost uses from the factory Also, you can rest easy that we verify that the trigger wheel teeth for the cam sensors are in their OEM location on every cam we sell!
***Our cams are made in the USA, in small batches so we can control the quality Sometimes the small quantities causes us to run out of stock before we get new batches finished Lead time can vary from 24hrs if we have them in stock, to 4 weeks if they have to be ordered If you are in a hurry, please e-mail sales@esslingeracing.comor call the office @ (909) 539-0544 ext 3 for current availability and lead time These cams areNOT CARB-legal for use on pollution controlled vehicles!
